Minelab Vanquish 560
Minelab — vanquish-560

Minelab Vanquish 560

A metal detector from Minelab aimed at family and holiday detectorists starting out — its Multi-IQ — simultaneous multi-frequency capability in a unit designed to be lived with, not just tested.

Multi-IQ — simultaneous multi-frequency
Price on request
Order on WhatsApp Call to ask

Minelab Vanquish 560 price in Pakistan

The Minelab Vanquish 560 is priced on request because import costs change often — message us on WhatsApp for today's price. Every unit is original with manufacturer warranty, and we deliver to every city in Pakistan.

Minelab Vanquish 560 overview

If your work is detectorists working farmland and old town sites, the Minelab Vanquish 560 from Minelab is worth a look. The core spec is its Multi-IQ — simultaneous multi-frequency capability.

What separates it day to day is multi-iq technology, v12x coil and 30 discrimination segments and 4 iron-bias levels — details that matter more once you're a few hours into a search than any spec sheet line.

The box ships with 6 items, enough to be field-ready out of the case.

Minelab Vanquish 560 key features

Multi-IQ technology

reads numerous frequencies in parallel, so performance stays uniform as you move covering assorted ground.

V12X coil

At 12×9 in, this Double-D coil covers more ground per pass than the smaller coils fitted to the 360 and 460.

30 discrimination segments and 4 iron-bias levels

the closest sorting control in the Vanquish range for telling targets from debris.

5 target tones

hands you the option to judge target type by ear before you even glance at the screen.

Fully waterproof IP68

the entire unit resists submersion to 5 meters, more than just splashes.

Bluetooth LE (LC3) wireless audio

keeps cordless headphone sound tightly in sync with what the coil senses.

Battery lasting up to 10 hours

Enough for a full day of detecting between magnetic USB-C recharges.

PARK Mode

tuned for the debris-heavy ground typical of parks and other crowded public spaces.

FIELD Mode

weighs depth against discrimination for farmland and long-studied archaeological sites.

BEACH Mode

works wet or dry sand, helped by the full 5-meter sealed rating.

User Profile

stores your own settings so you don't have to be rebuilding a setup each visit.

Technical specs

Technology Multi-IQ — simultaneous multi-frequency
Search Modes Park, Field, Beach, and a custom User Profile (4 total)
Pinpoint Mode Yes
Noise Cancel Automatic
Sensitivity 10 levels
Volume 10 levels (for general audio and iron-tone response)
Target Tones 5 tones for finer audio separation
Discrimination Segments 30 segments
Iron Bias 4 levels
Wireless Audio Low-latency Bluetooth LE (LC3) + included wired headphones
Vibration Handle vibration alert for noisy environments
Display Monochrome red LED display, backlit, with built-in flashlight
Standard Search Coil V12X elliptical 12×9 inch Double-D, high coverage
Length Extended: 142cm (56 in) / Collapsed: 79cm (31 in)
Weight 1.26 kg
Battery Internal lithium-ion battery, up to 10 hours runtime (magnetic USB-C charging)
Water Resistance Fully waterproof to 5 meters (IP68)
Warranty 3 years on the device and coil
Made in Australia
Detects Coins, jewelry, relics, gold

What's in the box
